METHODS TO INSTALL YOUR ARTISTRY IN ARCHITECTURAL GRILLES PRODUCTS
1. CORE ONLY
Drop in core which can be used for multiple applications where either blocking, wood work, angle or support is in place for the core to rest upon.
2. CORE ONLY
WITH MOUNTING TABS
Core only with mounting tabs for fastening to blocking, wood work or angle supports, duct flanges etc. AAG provides mounting fasteners with matching finish.
3. CORE ONLY
WITH MOUNTING TABS – SURFACE MOUNT
Core only with mounting tabs, typically used for wall cladding or other decorative purposes. AAG provides mounting fasteners.
4. A FRAME
DROP IN
Drop in A Frame typically used for an enclosure, fin tube opening, floor vents and millwork.
5. A FRAME
WITH MOUNTING HOLES
A Frame with countersunk mounting holes in the bottom of the frame.
Typical uses are for wall, ceiling, floor, toe-kicks and under benches.
AAG provides mounting fasteners.
6. A FRAME
WITH MOUNTING TABS
A Frame with countersunk mounting holes on the inside of frame for fastening to the opening. Always with removable core. Used for wall and ceiling applications. AAG provides mounting fasteners.
7. B FRAME
DROP IN
Drop in B Frame typically used for a rough cut opening since the flange provides a crisp, clean, finished appearance.
8. B FRAME
DROP IN ROUTED OPENING
Drop in B Frame placed into an opening that has routed edges so that the flange is flush to the surrounding surface.
9. B FRAME
SURFACE MOUNTED WITH HOLES
Surface mounted B Frame with countersunk mounting holes in the flange usually for wall or ceiling.
10. B FRAME
MOUNTING HOLES – REMOVABLE CORE
Surface mounted B Frame with countersunk mounting holes in the flange and removable core. For ceiling and walls where access is important.
11. B FRAME
CONCEALED MOUNTING HOLES – REMOVABLE CORE
B Frame with countersunk mounting holes through the side of frame for fastening to opening, with removable core. For ceiling and walls where access is important.
12. B FRAME
MOUNTING TABS
B Frame with mounting tabs for securing to blocking, mill work, supports, angle or duct flange.
13. B FRAME
REINFORCED CROSS BARS
B Frame with reinforced cross bars for floor or heavy traffic application. Additional reinforcement provided with custom cross bar spacing.
14. B FRAME
INVERTED WITH MOUNTING HOLES
Inverted B Frame with countersunk mounting holes in the flange – used in millwork, as a thru-door grille or under mount for a counter.
15. C FRAME
DROP IN
C Frame drop in application typically used for floor or sill application.
16. C FRAME
MOUNTING HOLES – REMOVABLE CORE
C Frame with countersunk mounting holes in side of frame for fastening to opening, with removable core; wall and ceiling applications.
17. C FRAME
CONCEALED MOUNTING HOLES – REMOVABLE CORE
C Frame with countersunk mounting holes in side of frame for fastening to opening, with removable core; wall and ceiling applications.
18. BAND FRAME
DROP IN
Drop in Band Frame for enclosures, millwork, and fin tube openings.
19. BAND FRAME
WITH MOUNTING TABS
Band Frame with mounting tabs for wall and ceiling applications
20. BAND FRAME
CONCEALED MOUNTING HOLES – REMOVABLE CORE
Band Frame with countersunk holes in the side of frame for fastening to the opening, with removable core; wall and ceiling applications.
21. JBEAD FRAME
FIXED CORE
JBead Frame for wall and ceiling applications with fixed core.
22. JBEAD FRAME
REMOVABLE CORE
JBead Frame with removable core for wall and ceiling applications.
